Luxman EQ-500 Vacuum Tube Phono Amplifier
Luxman EQ-500 Vacuum Tube Phono Amplifier Discover the True Essence of Analog Sound with the Luxman EQ-500 Experience the harmonic richness and tonal character of...
Vendor:
Luxman
- $6,695.00
-
- $6,695.00
- Unit price
- per
Contact Us To Reserve Future Product.
Subtotal:
$6,695.00
Free Shipping
Free Returns
Learn More.
Description
xLuxman EQ-500 Vacuum Tube Phono Amplifier
Discover the True Essence of Analog Sound with the Luxman EQ-500
Experience the harmonic richness and tonal character of vinyl playback like never before with the Luxman EQ-500 vacuum tube phono equalizer amplifier. Designed to faithfully reproduce the sound vibrations and resonance inscribed on analog records without interruption, this amplifier offers an extensive range of fine adjustments and switching functions to help you recreate the ideal sound from your memory.
RIAA-dedicated Non-feedback CR Type Amplification Circuit
All stages of the EQ-500 are vacuum tube, featuring low impedance and low distortion, ensuring an excellent sound quality supported by linear characteristics. With over half a century of experience in manufacturing vacuum tube amplifiers, Luxman has achieved the ultimate in high-grade analog reproduction in the EQ-500.
Elegant Design with Pointer-Type Analog Meters
The stylish, thin chassis of the EQ-500 is easy to mount on a control amplifier and features pointer-type analog VU meters with a sensitivity selection switch. The blaster white front panel houses additional control switches to create the perfect sound for your taste.
Optimizing Cartridge Load Adjustment
With 6 selectable load capacity levels and a load impedance selection function, the EQ-500 allows you to fully exploit the original potential of your cartridge for an unparalleled listening experience.
Control Functions for a Customized Listening Experience
Easily access all main control functions on the EQ-500's front panel, including articulator function, gain selection, output selection, phase invert, monaural mode, and low cut and high cut switches.
Technical Specifications:
| Specification | Details |
|---|---|
| Circuiting System | SRPP, Final Stage Cathode Follower, Non-feedback CR Type Equalizer |
| Vacuum Tubes Used | ECC83 x 4, ECC82 x 2, EZ81 x 1 |
| Input Sensitivity (1kHz) | MM: 4mV, MC: high 0.44mV, MC: low 0.18mV |
| Input Impedance | MM: 30kΩ to 100kΩ (variable), MC: high 40Ω, MC: low 2.5Ω |
| Rated Output/Output Impedance | 250mV/850Ω |
| Gain (1kHz) | MM: 36dB, MC: high 55dB, MC: low 63dB |
| Maximum Allowable Input (1kHz) | MM: 300mV, MC: high 34mV, MC: low 13mV |
| RIAA Deviation | ±0.3dB (20Hz to 20kHz) |
| Channel Separation (10kHz) | 65dB |
| Input | Unbalanced Line x 3 |
| Output | Unbalanced Line x 2, Balanced Line x 1 |
| Power Supply | 230V~(50Hz) / 115V~(60Hz) |
| Power Consumption | 47W |
| External Dimensions | 440(W) x 92(H) x 397(D) mm |
| Net Weight | 12.5kg (main unit) |
